YS-1000B Semi-auto Component Taping Machine
Product Overview
The YS-1000B Semi-auto Component Taping Machine is a precision-engineered solution for efficient component packaging and taping operations in electronic manufacturing environments.
Key Features
- Adjustable track width from 8mm to 72mm with easy-to-operate control screen
- Fine adjustment head in hot-press device with 0.1±mm precision and independent PID temperature control
- Cover tape position fine adjustment through moving tape tension control
- Fiber-optic counting system with leakage detection for accurate braiding
- Continuously adjustable moving tape speed with pedal control, compatible with ELA-481 standard plastic reels
Technical Specifications
| Model |
YS-1000B |
| Inspection System |
CCD Check Function |
| Machine Dimensions |
1650 × 460 × 580mm (L × H × W) |
| Feeding Compatibility |
ELA-481 standard wheel and cover tape |
| Tape Width Range |
12mm-72mm (8mm requires customization) |
| Power Supply |
AC200V 50HZ |
| Operating Pressure |
3.0kg/cm² |
| Temperature Control |
Dual-head independent PID control, range 20-200°C |
| Taping Speed |
3000-7000 PCS/hour (component dependent) |
| Counting System |
Fiber-optic sensitive counter |
| Package Type |
Self-adhesive or hot sealing |
| Weight |
50KG |
Packaging & Shipping
Our Services
Company Information
YUSH Electronic Technology Co., Ltd is a professional manufacturer and trader specializing in the research, development, and production of PCB depaneling machines, hot bar welding machines, and touch screen film sticking machines. Located in Dongguan City, Guangdong Province, China, our facility benefits from convenient transportation access. All products comply with international quality standards and are appreciated in markets worldwide. We welcome custom orders and look forward to establishing successful business relationships with clients globally.
Frequently Asked Questions
Who are we?
Based in Jiangsu, China since 2014, we serve global markets including Eastern Europe (20%), North America (20%), South America (15%), Southern Europe (10%), Northern Europe (10%), Western Europe (10%), South Asia (10%), and Mid East (5%). Our organization employs 301-500 professionals.
How do we guarantee quality?
We maintain quality through pre-production samples before mass production and final inspection before shipment.
What products do we offer?
Our product range includes PCB depaneling machines, PCB separators, PCB cutting machines, PCB depaneling equipment, and V-cut machines.
Why choose us over other suppliers?
Founded in 2004 and located in Jiangsu's manufacturing hub, YUSH Electronic Technology brings professional expertise in PCB separator and depanelizer electronic equipment machinery with advanced production facilities and experienced teams.
What services do we provide?
We accept delivery terms: FOB, CIF, EXW, DDP, DDU, Express Delivery, DAF. Payment options include USD, EUR, JPY, CAD, AUD, HKD, GBP, CNY, CHF currencies and T/T, L/C, D/P D/A, MoneyGram, Credit Card, PayPal, Western Union, Cash, Escrow payment methods. Languages spoken: English, Chinese, Spanish, Japanese, Portuguese, German, Arabic, Korean, Hindi.
